Round Glass Coverslips
Made from clear, high transmissive boro silicate glass. Cleaned, cut and packed in either 1 oz., 1/4 oz. or pkg/100.
Available in various popular sizes ranging from Ø10 to Ø22mm. Not sterile.
Pieces Per Ounce Table
Schott D263M Glass Coverslips Technical Data |
Prod #
| Description
| Unit
| Qty
| Price
| Order / Quote
|
Thickness #1, .13-.17mm
|
260367
| Coverslips, Glass, 10mm dia.
| pkg/1 oz
| 1+
| $286.00
|
|
Thickness #1.5, 0.16-0.19mm
|
260368
| Coverslips, Glass, 10mm dia.
| pkg/100
| 1+
| 93.80
|
|
Thickness #1, 0.13-0.16mm
|
26020
| Coverslips, Glass, 12mm dia.
| 1 oz
| 1+
| 130.90
|
|
26023
| Coverslips, Glass, 12mm dia.
| 1/4 oz
| 1-3
| 35.00
|
|
4+
| 32.50
|
26021
| Coverslips, Glass, 15mm dia.
| 1 oz
| 1+
| 91.90
|
|
26024
| Coverslips, Glass, 15mm dia.
| 1/4 oz
| 1-3
| 26.40
|
|
4+
| 25.00
|
26022
| Coverslips, Glass, 18mm dia.
| 1 oz
| 1+
| 70.40
|
|
260369
| Coverslips, Glass, 22mm dia.
| 1 oz
| 1+
| 76.10
|
|
|
Micro Glass Coverslips
- Individually selected
- Superior quality
- Cleaned, cut, sorted and made of especially processed borosilicate glass (Type D263M)
- Not sterile
Schott D263M Glass Coverslips Technical Data
Prod #
| Description
| Unit
| Qty
| Price
| Order / Quote
|
Thickness #1, 0.13-0.16mm
|
260140
| Micro Cover Glasses, 22 x 22mm x 0.13 - 0.16mm thick
| 1 ounce.
| 1-9
| $8.80
|
|
10+
| 7.70
|
260142
| Micro Cover Glasses, 22 x 30mm x 0.13 - 0.16mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.20
|
260144
| Micro Cover Glasses, 22 x 40mm x 0.13 - 0.16mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.20
|
260146
| Micro Cover Glasses, 22 x 50mm x 0.13 - 0.16mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.20
|
Thickness #1.5, 0.16-0.19mm
|
260148
| Micro Cover Glasses, 22 x 22mm x 0.16 - 0.19mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.00
|
260150
| Micro Cover Glasses, 22 x 30mm x 0.16 - 0.19mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.20
|
260152
| Micro Cover Glasses, 22 x 40mm x 0.16 - 0.19mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.20
|
260154
| Micro Cover Glasses, 22 x 50mm x 0.16 - 0.19mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.20
|
Thickness #2, 0.19-0.25mm
|
260156
| Micro Cover Glasses, 22 x 22mm x 0.19 - 0.25mm thick
| 1 ounce
| 1-9
| 8.80
|
|
10+
| 7.20
|
260160
| Micro Cover Glasses, 22 x 40mm x 0.19 - 0.25mm thick
| 1 ounce
| 1-9
| 7.70
|
|
10+
| 6.70
|
|
Superslip® Micro Cover Glasses
- For use in automatic coverslippers
- Not sterile
Schott D263M Glass Coverslips Technical Data
Prod #
| Description
| Unit
| Qty
| Price
| Order / Quote
|
Thickness #1, 0.13-0.16mm
|
260164
| Superslip® Cover Glasses, 24 x 40mm x 0.13 - 0.16mm thick
| 1 oz.
| 1-9
| $12.10
|
|
10+
| 10.60
|
260166
| Superslip® Cover Glasses, 24 x 50mm x 0.13 - 0.16mm thick
| 1 oz.
| 1-9
| 9.90
|
|
10+
| 8.70
|
260168
| Superslip® Cover Glasses, 24 x 60mm x 0.13 - 0.16mm thick
| 1 oz.
| 1-9
| 12.10
|
|
10+
| 10.50
|
|
Prod #
| Description
| Unit
| Qty
| Price
| Order / Quote
|
Thickness #0, Standard Squares, 0.08-0.13mm
|
260300
| Cover Glass, No. 0, 22 x 22mm
| 1 oz.
| 1-9
| $55.00
|
|
10+
| 51.10
|
Thickness #1, Standard Squares, 0.13-0.16mm
|
260340
| Cover Glass, No. 1, 18 x 18mm
| 1 oz.
| 1-9
| 26.40
|
|
10+
| 24.30
|
260341
| Cover Glass, No. 1, 22 x 22mm
| 1 oz.
| 1-9
| 28.60
|
|
10+
| 24.00
|
260342
| Cover Glass, No. 1, 25 x 25mm
| 1 oz.
| 1-9
| 28.60
|
|
10+
| 26.30
|
Thickness #1, Standard Rectangles, 0.13-0.16mm
|
260351
| Cover Glass, No. 1, 22 x 30mm
| 1 oz.
| 1-9
| 35.20
|
|
10+
| 32.40
|
260353
| Cover Glass, No. 1, 22 x 40mm
| 1 oz.
| 1-9
| 27.25
|
|
10+
| 24.88
|
260354
| Cover Glass, No. 1, 22 x 50mm
| 1 oz.
| 1-9
| 28.60
|
|
10+
| 25.90
|
260355
| Cover Glass, No. 1, 22 x 60mm
| 1 oz.
| 1-9
| 28.60
|
|
10+
| 25.90
|
260358
| Cover Glass, No. 1, 24 x 40mm
| 1 oz.
| 1-9
| 27.50
|
|
10+
| 25.30
|
260359
| Cover Glass, No. 1, 24 x 50mm
| 1 oz.
| 1-9
| 28.60
|
|
10+
| 25.90
|
260360
| Cover Glass, No. 1, 24 x 60mm
| 1 oz.
| 1-9
| 28.60
|
|
10+
| 25.90
|
260361
| Cover Glass, No. 1, 35 x 50mm
| 1 oz.
| 1-9
| 28.60
|
|
10+
| 25.70
|
Thickness #1, Standard Circles, 0.13-0.16mm
|
260372
| Cover Glass, No. 1, 25mm dia.
| 1 oz.
| 1-9
| 127.60
|
|
10+
| 120.90
|
Thickness #1.5, Standard Squares, 0.16-0.19mm
|
260405
| Cover Glass, No. 1.5, 18 x 18mm
| 1 oz.
| 1-9
| 27.50
|
|
10+
| 25.30
|
260406
| Cover Glass, No. 1.5, 22 x 22mm
| 1 oz.
| 1-9
| 23.10
|
|
10+
| 21.40
|
Thickness #1.5, Standard Rectangles, 0.16-0.19mm
|
260416
| Cover Glass, No. 1.5, 22 x 40mm
| 1 oz.
| 1-9
| 27.50
|
|
10+
| 24.70
|
260417
| Cover Glass, No. 1.5, 22 x 50mm
| 1 oz.
| 1-9
| 25.30
|
|
10+
| 22.70
|
260419
| Cover Glass, No. 1.5, 24 x 30mm
| 1 oz.
| 1-9
| 72.60
|
|
10+
| 67.40
|
260421
| Cover Glass, No. 1.5, 24 x 40mm
| 1 oz.
| 1-9
| 26.40
|
|
10+
| 23.70
|
260422
| Cover Glass, No. 1.5, 24 x 50mm
| 1 oz.
| 1-9
| 25.30
|
|
10+
| 23.70
|
260423
| Cover Glass, No. 1.5, 24 x 60mm
| 1 oz.
| 1-9
| 27.50
|
|
10+
| 24.80
|
Thickness #2, Standard Squares, 0.17-0.25mm
|
260435
| Cover Glass, No. 2, 22 x 22mm
| 1 oz.
| 1-9
| 18.70
|
|
10+
| 16.90
|
 |
Quartz Coverslips
Quartz Microscope Slides and Cover Slips are a necessity for microscopy applications
where UV transparency is needed. They can also be used for high end microscopy applications
to reduce signal los due to absorption. Other application can involve UV radiation
transparency. The quartz slides can also be used for high temperature applications
up to 1250°C (2282°F). Above this temperature the material will start to
soften. The Quartz material used to manufacturer our high quality quartz microscope
slides and cover slips is the GE 124 type high purity fused quartz, a well documented
quartz used over decades in microscopy applications.
Technical Iinformation about GE 124 Quartz |
Transparency is provided for 0.19 to 4.2um with very low absorbance in the 0.26 to 2.6um range.
Quartz Coverslips are available in several sizes and thicknesses, although for most
microscopy applications the 0.25mm thickness is adequate.
Not sterile.
Quartz Microscope Slides
Prod #
| Description
| Unit
| Price
| Order / Quote
|
Square Quartz Coverslips
|
26016
| Square Quartz Coverslip, 19 x 19 x 0.5mm thick
| each
| $15.40
|
|
26017
| Square Quartz Coverslip, 19 x 19 x 0.25mm thick
| each
| 30.80
|
|
26014
| Square Quartz Coverslip, 22 x 22 x 0.25mm thick
| each
| 33.30
|
|
Round Quartz Coverslips
|
26010
| Round Quartz Coverslip, Ø10mm x 0.25mm thick
| each
| 25.30
|
|
26042
| Round Quartz Coverslip, Ø15mm x 0.25mm thick
| each
| 23.10
|
|
26019
| Round Quartz Coverslip, Ø18mm x 0.25mm thick
| each
| 28.60
|
|
26018
| Round Quartz Coverslip, Ø25.4mm x 0.25mm thick
| each
| 41.80
|
|
26043
| Round Quartz Coverslip, Ø33mm x 0.25mm thick
| each
| 41.80
|
|
 |
Large Cover Glass, Thickness #2
Thickness: #2 (0.19-0.25mm)
Packaging: 25, 36 or 50 cover glasses in shrink-wrapped package |
Large cover glass specially made for the large microscope slides. Made from optical grade borosilicate glass. Sizes available 3 x 3-1/4" up to 4-1/2 x 6-1/4".
Typical Values of Coverglass (39KB PDF)
Prod #
| Description
| Unit
| Price
| Order / Quote
|
260450
| Large Cover Glass 3" x 3-1/4" (76 x 83mm)
| pkg/36
| $181.25
|
|
260451
| Large Cover Glass 3 x 3-1/2" (76 x 89mm)
| pkg/50
| 181.25
|
|
260452
| Large Cover Glass 3-3/4 x 4-1/2" (95 x 114mm)
| pkg/50
| 212.50
|
|
260454
| Large Cover Glass 4-1/2 x 6-1/4" (114 x 159mm)
| pkg/25
| 292.95
|
|
Large Cover Glasses, Thickness #1
Thickness: #1 (0.13 to 0.17mm)
Made of optical grade borosilicate glass. Made for the large microscope slides of
3" x 2" or larger.
Typical Values of Coverglass (39KB PDF)
Prod #
| Description
| Unit
| Price
| Order / Quote
|
260460-100
| Cover Glass, 36 x 60mm (1.42 x 2.36"), Thickness No. 1
| pkg/100
| $88.25
|
|
260461-100
| Cover Glass, 36 x 60mm (1.42 x 2.36"), Thickness No. 1.5
| pkg/100
| 82.50
|
|
260462-100
| Cover Glass, 50 x 75mm (1.96 x 2.95"), Thickness No. 1
| pkg/100
| 201.50
|
|
|
 |
ClariTex Cover Glass for HISTOBOND® + and ClariTex Super Mega Slides
This coverglass is sized to match the working area of the HISTOBOND® + Super Mega Slide.
Thickness: #1.5, #1
Dimensions: 64 x 50mm
ClariTex
Super Mega
Glass Microscope Slides |
Prod #
| Description
| Unit
| Price
| Order / Quote
|
260378
| ClariTex Coverglass for Super Mega Slides, #1.5 Thickness, 64 x 50mm
| pkg/100
| $36.50
|
|
260378-1
| ClariTex Coverglass for Super Mega Slides, #1 Thickness, 64 x 50mm
| pkg/100
| 40.00
|
|
|
|
Handi-Vac® Coverslip Pick-Up Tool
Simple hand actuated vacuum pump with 1/2" straight tip and 9.3mm (3/8") silicone cup to pick up
coverslips, mica and Si chips.
- ESD safe rubber body
- Will pick-up and hold up to 35g
- Easily picks up cover glasses, mica or silicon discs for accurate placement
- No scratch silicone rubber cup
- More user friendly than conventional metal tweezers
|
|
Prod #
| Description
| Unit
| Price
| Order / Quote
|
528-99
| Handi-Vac® Coverslip Pick-Up Tool
| each
| $21.85
|
|
|
|
PELCO® Gold Coated Glass Coverslips
High quality, borosilicate glass coverslips coated with 50nm of gold with a 5nm chromium
adhesion layer between the coverslip surface and the gold coating. Can be used for a wide
range of nanotechnology, biotechnology and AFM application. Both Cr and Au are evaporated
on the glass coverslips using a vacuum evaporation system. The gold surface is not atomically
flat, but has bumps in the nm range. The coverslips are sold in packs of 2 and are packed in
an X0 Gel-Pak box. The gold coated coverslips are autoclavable.
Specifications:
Glass coverslips size: Ø16mm with thickness #1 (0.13-0.16mm) or 22x22mm with thickness #2
(0.19-0.25mm)
Glass type: Schott D263M borosilicate
Chromium adhesion layer thickness: 5nm
Gold substrate layer thickness: 50nm (±5nm)
Gold purity: 99.999%
PELCO® Pro Gold Plated Tweezers
|
Prod #
| Description
| Unit
| Price
| Order / Quote
|
260156-G
| Gold Coated 22 x 22mm Glass Coverslips, 50nm Au
| pkg/2
| $106.70
|
|
260374-G
| Gold Coated Ø16mm Glass Coverslips, 50nm Au
| pkg/2
| 77.00
|
|
|
Approximate PIECES per OUNCE for
Standard Size Microscope Cover Glasses*
|
Thickness |
Size (mm) |
#0
(0.08-0.13mm) |
#1
(0.13-0.17mm) |
#1.5
(0.16-0.19mm) |
#2
(0.17-0.25mm) |
18 x 18 |
320 |
233 |
202 |
165 |
22 x 22 |
208 |
156 |
138 |
116 |
22 x 30 |
156 |
116 |
102 |
86 |
22 x 35 |
135 |
100 |
87 |
72 |
22 x 40 |
116 |
87 |
76 |
64 |
22 x 50 |
94 |
70 |
61 |
52 |
22 x 60 |
78 |
58 |
51 |
43 |
24 x 30 |
144 |
108 |
94 |
78 |
24 x 35 |
126 |
94 |
82 |
68 |
24 x 40 |
108 |
80 |
70 |
59 |
24 x 50 |
90 |
67 |
58 |
49 |
24 x 60 |
72 |
54 |
47 |
39 |
25 x 25 |
166 |
124 |
108 |
89 |
35 x 50 |
- |
41 |
- |
- |
35 x 60 |
- |
37 |
- |
- |
43 x 50 |
- |
35 |
- |
- |
48 x 60 |
- |
26 |
- |
- |
48 x 65 |
- |
24 |
- |
- |
10mm dia. |
999 |
735 |
636 |
533 |
12mm dia. |
932 |
692 |
597 |
502 |
13mm dia. |
776 |
575 |
500 |
425 |
15mm dia. |
602 |
443 |
383 |
321 |
16mm dia. |
510 |
376 |
330 |
280 |
18mm dia. |
415 |
308 |
266 |
223 |
19mm dia. |
372 |
276 |
238 |
200 |
22mm dia. |
276 |
206 |
178 |
150 |
25mm dia. |
215 |
159 |
137 |
116 |
*Note: Not all sizes listed are available
USA / Canada: Telephone: 530-243-2200; 800-237-3526; Fax 530-243-3761; Email: [email protected]
International: Telephone: 530-243-2200; Fax 530-243-3761; Email: [email protected]
Copyright © Ted Pella, Inc., 1996-2023.
All rights reserved.
All trademarks
are the property of their respective owners.
|
