Conductive graphite paint, primarily designed for SEM sample preparation. The graphite flakes, with an average size of 1µm, are bonded by a cellulose resin with isopropanol as diluent. Good bonding properties on most materials. Graphite content is 20%. Ideal to mount samples on sample stubs or to make a conductive path to the sample surface. Let fully dry before using in the SEM. Maximum service temperature: 200° C. Use Graphite Paint Extender to dilute when needed.
Technical Notes, PELCO® Conductive Graphite Isopropanol Based (116KB PDF) F, I - 16053, 16053-20, 16053-SPC SDS (184KB PDF) F, I - 16054 SDS (126KB PDF)
Conductive Adhesives Comparison Table
These carbon tapes are conductive and may be used conveniently for scanning electron microscopy or EDS applications.
This is the same material as the PELCO Tabs™, Carbon Conductive Tabs, but in tape form. The tape form allows for special application uses such as custom sizes, cut-outs and shapes. The purity of this tape is identical to the PELCO Tabs™; only very small impurities of Al and Si may be found.
Both sides of the tape have a thick conductive adhesive (conductive inner film is 35µm and the adhesive is 45µm on each side for a total of 125µm [5 mils]) with a white liner. The double adhesive and conductive design permits quick mounting of samples without using liquid or colloidal adhesives.
The tape is relatively solid and non-porous and does not absorb small samples. The variety of widths affords efficient application to various specimen mount surface sizes. Thickness is 0.16mm. Available in six widths. Can be used down to -20°C (-4°F) and temperature maximum is 60°C (140°F). Available in 5, 8, 12, 20, 25, and 50mm W x 20m L (0.19, 0.31, 0.47, 0.79, 0.98, and 1.96" x 21.8 yd). Core diameter is 76mm (3"). SEM mounts not included.
Versatile, cost effective SEM pin mount storage box and holder for pin mounts with a 3.2mm (1/8") pin. Numbered 1-18 with the spacing designed to accommodate all types of pin mounts with a diameter from 6.4 to 50mm. Can hold 18 of 12.7mm pin mounts, 8 of 25mm pin mounts, 2 of 32 or 38 or 50mm pin mounts with space left for the smaller pin mounts. Maximum specimen space (between mount surface and closed lid) is 16mm (5/8").
Round cotton heads with polypropylene handles. Total length is 7.6cm (3"). Sold as pack of 100.
Pointed cotton heads with polypropylene handles. Total length is 7.6cm (3"). Sold as pack of 200.
A neat way to hold tissue for mincing or to move and sort samples. May also be used for cleaning apertures or as an applicator stick. Pointed on one end. Available in 15 and 20cm (6" and 8") length. Diameter is approximately 2.75mm (0.11"). Sold in packages of 100.
Cleaned, packaged in a clear dispenser with exit hole to keep the picks clean. Useful for picking, cleaning, sorting and holding. Double-pointed, 65mm L (2-1/2").
Made of natural latex, molded and double-dipped for high elasticity with a smooth, comfortable fit. Gloves have a protective beaded cuff and fit either hand. Non-sterile. Powder-free.
Length: 9" (230mm) Thickness: 5 mil (0.13mm)
Ultra-soft, next generation nitrile formulation provides the relaxed, comfortable fit and feel that you would expect from a latex glove. The strong, high quality nitrile offers reliable barrier protection against many hazardous and infectious substances. Inexpensive and disposable, use to avoid cross contamination. Textured fingers provide an outstanding grip in wet and dry environments. A superior value, ambidextrous, synthetic glove that has a beaded cuff and is powder-free. 100 gloves per dispenser box.
Average Length: 9.6" (245mm) Size L Palm Thickness: 2 mil (0.05mm) Finger Thickness: 3 mil (0.07mm)
Lintless, pure cotton, cut on a bias. For sensitive EM polishing and cleaning applications. Sizes: 4" x 4" (10.2 x 10.2cm); 6" x 6" (15.2 x 15.2cm); 9" x 9" (22.9 x 22.9cm); 17" x 17" (43.2 x 43.2cm)
MSDS (97KB PDF) more cloths
Class 100 cleanroom compatible cleaning wipes, pre-saturated with 70% Isopropyl alcohol and 30% deionized water. The fabric is constructed of continuous polypropylene fibers bonded with together with a meltblown process. This ensures superior strength with low fiber and particulate generation.
The solvent ratio has been found most effective for cleaning and provides efficient drying without leaving a residue. Wipes are packed in a resealable polyethylene pouch.
Perfect for general cleaning, maintenance, wipe-down, final inspection and field use. Complete Selection of Wipes
PELCO® Pin Mount Starter Kits contain a selection of the most popular pin mounts together with conductive silver and carbon paint, conductive carbon tabs and SEM mount grippers. All supplied and stored in a convenient and practical storage box.
See kit contents and ordering information below.
