Specifications for the
208C High Vacuum Turbo Carbon Coater

208C High Vacuum Turbo Carbon Coater

Specifications
Chamber Size 150mm OD x 165mm high (5.9" x 6.5") standard
Variable height, 165mm - 250mm (6.5" - 9.8") optional
Evaporation source Bradley type (6.15mm OD rods [1/4"])
Heavy duty stainless construction
Evaporation supply Microprocessor based Feedback loop controlled with remote current/voltage sensing
Safety interlocked
Variable, 135A max. with over-current protection
Sample stage Static table holds 12 SEM 1/2" stubs
Height adjustment through 60mm
Optional rotary-planetary-tilting stage
Analog metering Vacuum, dual range Atm - 0.001mb
1 x 10-3mb to 5 x 10-6
Current, 0 - 200A
Control method Automatic evaporation control using programmed voltage and timer
Full manual override with pulsed or continuous operation
Digital timer, 1 - 9.9 seconds
Digital voltage setting, 0.1 - 5.5V
Automatic vent

Pumping System
Configuration Turbo/rotary pump combination
Optional Dry Scroll Pump instead of rotary pump
Pumping speed 67 l/sec.
Pumpdown time 1.5 min. to 1 x 10-4mb
Ultimate pressure 5 x 10-6mb
Desktop system Rotary pump is mounted on desktop compatible anti-vibration table
All metal vacuum coupling system

Services required
Supply 100-120 or 200-240 VAC, 50/60Hz
Power 1200 VA max.

System Dimensions
Size Width 600mm (23.6"), Depth 600mm (23.6"), Height 360mm (14.2")
Weight 45Kg (99.5 lbs) coater and pumps



Footprint

coater for scanning electron microscopy
Dimensions (mm)
1. Control unit
2. Vacuum chamber
3. Thickness monitor 		4. Turbo Molecular Pump
5. Rotary pump and
Anti-vibration base
